The objective of this dissertation is to shed light on the intze water tank designed considering the earthquake forces according to indian standard code.

Intze water tank components.

Intze tank painting to new columns of tank portion with 2 coats of water proof cement paint of approved brand and shade over a base coat of approved cement primer grade i making making 3 coats in all to give an even shade after thourughly brushing the surface to remove all dirt and remains of loose powdered materials including cost and. A water tower built in accordance with the intze principle has a brick shaft on which the water tank sits. Shaft rested water tank used in is 1893. There is comparative design of intze type water tank by membrane design and continuity analysis.

Design and detail all structural components. They are critical elements in municipal water supply fire fighting systems and in many industrial facilities for storage of water. The basic preference for this kind of tank. Take live load 1 5 kn m2.

The tanks can be made in different shapes and sizes usually circular and rectangular shapes are widely used. Fix the basic dimensions of elevated intze water tank to store 6 lacs litre water. Intze prinzip these name provided to build different standards named after water powered engineer otto intze 1843 1904 in one case the intze standard identifies water tower and other case is requesting dam. The design is go verned by the location of tanks i e.

Raised water storage tanks components to search for quality and toughness and of. Two mass 2 4 elevated tank structural elements of intze tank the various structural elements of an intze type tank comprises of the following. 3370 2009 and draft code 1893 part 2 2005 considering two mass modal i e. 1 1 intze tank the intze guideline is a german word.

Overhead on ground or underground water tanks. Water tanks are very important components of lifeline. Use m30 grade concrete and fe415 grade steel. Usage of water tanks a reinforcement concrete tank is a.

Column rested water tank mass idealization of the tank is more appropriate as b. Top spherical dome 2 top ring beam 3. Intze tank supported on frame staging also this report includes. Intzetank technicalcivil designofintzetank must watch previous videos of.

The base of the tank is fixed with a ring anchor ringanker made of iron or steel so that only vertical not horizontal forces are transmitted to the tower due to the lack of horizontal forces the tower shaft does not need to be quite as solidly built. Reinforced concrete water tank design is based on is 3370. 2009 parts i iv. It has been produced around 80 years prior and perceived also outlined effective and temperate unit for business and private use.
